HML45M02 450MX Brushless Motor(1700KV)
Preço62,29€
|
Product: | |
|
|
Product: | |
|
|
Specification Drawing: | |
|
|
Wiring Schematic Drawing: | |
|
|
Package: | |
|
|
Test Data Graph:450MX(3400KV),15T,BATT 3S 11.1V ,3D Flight Record | |
|
|
Test Data Graph:450MX(1700KV),15T,BATT 6S 22.2V ,3D Flight Record | |
|
|
Instructions: | Specification: |
1.The 450MX motor incorporates radial fan in its end bell, creating powerful airflow to dissipate heat. Tweaks to motor design and reduction in weight not only contributes to dramatic power increase, the high efficiency cooling system enables cooler operating temperature during and after flights when compared to motor of previous generation.
|
●Input voltage:DC7.4-22.2V 2-6cell Li-Po ●Max continuous current:30A/45A(5sec) ●Max output power:Approx. 650w/970W(5sec) ●KV value:1700KV ●Dimension:spindle 3.5x29.2x38mm ●Weight:Approx. 83g |
Accessories: | |
●Socket button head screw(M2.5X6mm)X2 ●Washer(Φ2.6XΦ5.8X0.6mm)X2 ●ALIGN standard 3mm gilt terminal x 3set |
