LX0401    Lynx Heli Tail Servo Mount 130X Red Devil Edition

The details and design of this tail servo support add top performance and an exotic look to your 130X tail system, giving you the opportunity of fully enjoy the superior DS35 servo performance.

FEATURES:
- Dedicated design for DS 35 servo support.
- Built-in reference pin for the correct servo installation, will give the plug and play features.
- Direct replacement for the standard 130 X tail parts, when DS 35 servo is used.
- Optimized servo clamping assure superior holding without deform servo case.
- Increased tail system performance, achieved by DS35 servo specification.
- FEA (Final Elements Analysis) design assistance, achieving the lightest weight with the maximum strength.

TECHNICAL SPECIFICATIONS:
- Tail servo support material: Aluminum 7075-T6 –red anodized finish
- Screw material: Carbon steel plated
- Tail case assembled weight: 1.2g

PACKING LIST:
1 x CNC 130X – DS35 tail servo support
2 x M1.4x4 Pan Head screws
2 x M1.4x6 Pan Head screws
