HE50H09 RCE-G600 Governor ur RCE-G600 - Align
 As imagens são meramente ilustrativas e sem valor contratual Clique para ampliar |
Preço72,72€
|
| Product: | |
| Illustration: | |
 |
|
| Package: | |
 |
|
| Instructions: | Specification: |
|
●Compact design, easy use, simple setting with great speed control performance. ●Speed resolution: 0.1RPM ●Speed stability accuracy: within 1%(Steady State) ●Not apply to S9251、S9256 and other 760μs servos. |
●Operating voltage:DC4.5V-6V ●Consumption current:<20mA@4.8V ●Direct detection of engine rotation speed. ●Speed control range:10500~21000RPM ●Servo RWM output pulse width: 1~2ms，not apply to S9251、S9256 and other 760μs servos. ●Operating temperature range:-20°C~85°C ●Operating moisture range:0%~95% ●Case size(body):28.5x26.2x9mm ●Signal wire length:160mm ●Sensor wire length:250mm ●Weight:10g(including wires) |
| Accessories: | |
|
●RPM Magnet x 2(Φ4x1.5mm) ●Socket button head screw x 2(T2.6x6mm) ●Nut x 1 |
|
